Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | Q8P1BXXSR230 |
| Color | Red |
| Current Rating | 3 mA |
| Lamp Size | 5 mm |
| Lamp Type | LED |
| Length | 1.574" (40mm) |
| Life | 100000 hrs. |
| Mounting Hole Size | 8 mm |
| Mounting Type | Threaded |
| Shop By | Factory Choice |
| Standards | UL |
| Supply Voltage | 230 VAC |
| Temperature Rating | -40 to 85 C |
| Termination | Solder |
| Type | General Purpose |
| UPC Code | 5056070961036 |
| Voltage Rating | 230 VAC |
| Warranty | 3 Year Warranty |
Overview
RS Pro 122571 Series — 8 mm Prominent or Recessed Panel Mount Indicators:
RS Pro prominent or recessed indicator with 8 mm mounting hole features green LEDs for panel mount applications. This indicator accommodates a lamp size of 5 mm and offers faston, solder lug termination. It has a voltage rating of 24 V ac. The indicator has a wide operating temperature range of -40 to 85°C, further increasing the potential applications they may be used for. The 5 mm LED requires an 8 mm panel cutout and is supplied with a fixing nut and spring washer. It offers a wide selection of voltage ratings, bezel finishes and bezel styles.
